ISOL-8 MiniSub Chroma High Performance Audio Video Mains Conditioner (6-Way)

ISOL-8 MiniSub Chroma High Performance 6-Way Mains Conditioner for A/V

The MiniSub Chroma combines the architecture of the VMC1080 and the acclaimed MiniSub Wave to bring pure power to AV systems in one convenient package.

Video, low and high current loads all need different treatment to allow a quality AV system to operate at peak potential. The same separated filter topology found across our high performance and audiophile products forms the basis of the Chroma allowing each equipment type to deliver peak performance.

One outlet has a special broadband Transmodal filter, implemented with custom magnetics, designed to sink noise from your video display's hard working power supply. This can improve picture detail and reduce motion artifacts.

For other low current loads, such as source and video playback components, there are three other outlets each with a separate filter network.

Separate filters are the feature that made the original MiniSub such a ground breaking product. It reduces system component cross contamination, stopping mains borne noise from one system component affecting others.

Unlike most other conditioners, which only deal with common mode noise, the video and low/med power outlets can suppress both common and differential mode noise, without shunting noise to ground thanks to our Transmodal filter topology.

For more demanding loads, like amplifiers, the separate high power section has a multistage filter using custom wound components with very low impedance. This cleans current hungry, noisy components effectively without squashing dynamic performance.

The MiniSub Chroma is hand crafted for outstanding build quality. We engineer our products rigorously to provide unbeatable performance that will last a lifetime. Inside the quality casework you will find the same carefully auditioned polypropylene capacitors, Mundorf OFC inductors, high grade connectors, and custom ISOL-8 chokes that are found in our high end audiophile products. You will also have the peace of mind that comes with our spike and surge protection. All ISOL-8 products are designed and manufactured in the UK and come with a five year guarantee in the UK.

The MiniSub Chroma is engineered to give your AV system an effective system wide upgrade with no compromise in audio pace, rhythm and timing. The clean, stable power supply it provides allows you to enjoy each and every performance delivered at maximum potential.

For further information download an E-Brochure here

• Number of available outlets: 6 (1 video display. 3 low/med current. 2 high current)
• Type of outlets available: 13A British chassis sockets / European Schuko sockets / 15A US sockets
• Standard Mains Inlet: 10A IEC fused at 10 Amps (cable not supplied)
• Dimensions: 444 x 85 x 305mm (W x H x D) excluding connectors
• Product Weight: 7.5Kg
• Construction: Steel chassis with black finish. Silver Aluminium front panel (Black optional)
• Mains Voltage: 230VAC version for 220-240VAC / 117VAC version for 100-127VAC
• Maximum Continuous Current: 4 Amps for video display power outlet / 6 Amps any one low/med power outlet / 6 Amps across all low/med power outlets / 10 Amps any one high power outlet / 10 Amps across all outlets
