IsoTek V5 Polaris 6-Way Power Conditioning Distribution Block

V5 Polaris Mains Power Conditioning 6-Way Distribution Block, by IsoTek.

Marking the entry point of IsoTek’s innovative and multi award-winning range of power line cleaning solutions, the new V5 Polaris offers nine times more Differential Mode filtering, improved amperage with decreased resistance along with a 60% improved Direct Current Resistance.

Protection is also doubled in this new model. V5 Polaris represents the most cost effective upgrade to any audio or audio-visual system, delivering improved performance and protection. It is astonishing value for money.

This unique circuit delivers clean power to its six outlet sockets – each one independently isolated to prevent cross-contamination of Differential Mode mains noise. This is combined with IsoTek’s KERP © (Kirchhoff’s Equal Resistance Path) to ensure equal resistance and equal power delivery to all outlets.

The internal wiring is of the highest standard, a unique 2sqmm design featuring pure 6n oxygen free copper conductor strands each silver-plated, these offer low resistance and high amperage.

An aerospace grade Fluorinated Ethylene Propylene (FEP) dielectric, with very low dielectric resistance is used to protect the conductors as well as giving an ideal conductor contact dielectric for the internal power delivery system.

Features

• Suitable for all audio or home theatre / home cinema systems
• RFI reduction 35 dB
• Central clean power network removes Common and Differential Mode mains noise
• 6 independent outlets stop Differential Mode cross contamination
• 45000 Amps instantaneous protection
• Fully star-earthed network
• Multi-strand 6N OFC silver-plated internal wiring with FEP dielectric
• System Link outlet for extending the outlets and maintaining a starred earth reference
• Supplied with IsoTek EVO3 Initium power cable (1.50 m)
• Provides up to 2300 watts (10A/230V) or 1150 watts (10A/115V) of clean power, ensuring optimal energy delivery for your equipment

Specifications

• Sockets / Outlets: 6
• Available Outlet Types: UK (Standard), EU, US, AU & CH (Special Order)
• System Link: 1
• Mains Inlet: 10A IEC C14
• Mains Voltage: 100-240V / 50-60Hz
• Max Current: 10A HRC
• Total Wattage: 2300 W (@ 230 V) / 1150 W (@ 115 V)
• Surge Protection: 45000 A
• Dimensions (W x H x D): 80 x 50 x 510 mm
• Weight: 1 kg
• Delivered with: EVO3 Initium 1.50 m Cable

Included

• 1 x V5 Polaris 6-Way Mains Distribution Block
• 1 x EVO3 Initium Mains Power Cable, 1.50 Metre

More Information

• V5 Polaris 6-Way, by IsoTek
