Van Den Hul The MC Silver IT 65G Stereo RCA Analogue Interconnect Cable

The MC Silver IT 65G Stereo RCA Analogue Interconnect Cable, by Van Den Hul.

This cable exhibits an extremely extended frequency range of 65 GigaHertz, and all production handling is done with extreme care with maximum attention paid to maintain a very constant characteristic impedance along the whole cable, as well as in the micro domain. All to prevent signal reflections even up to very high frequencies.

The centre lead consists of 19 extreme high grade Matched Crystal (MC) extruded OFC strands with a very thick and dense extruded Matched Crystal (MC) purest silver coating applied in a mechanical processing step. The diameter of this centre conductor is 1.4 mm. and the cross-section area is 1.17 mm².

The centre lead resistance is a remarkably low: 1.43 Ohm/100 m, whilst the typical capacitance is: 83 pF/meter. The insulation between core and shielding is made of Teflon tape in several layers exhibiting a typically low relative dielectric constant of 1.4.

,p>The double shielding is made of a 96 x 0.10 mm. Matched Crystal (MC) OFC wire braiding with a very thick and dense coating of very pure silver with underneath a helically overlapping wound very pure 2.5 x 0.05 mm. silver ribbon, and the external insulation is made of the special HULLIFLEX EHD material. This specific insulation material is too costly to be used in all Van Den Hul products.

Please note: Precautions must be taken to prevent bending around a very small radius. The minimum safe value of the bending radius is 58 mm. The external diameter of the MC – SILVER IT 65 G is: 5.8 mm.; a size that perfectly matches our 5.5 mm gold RCA connector.

Specifications

• Brand: Van Den Hul
• Range: The MC Silver IT 65G
• Conductor: Matched Crystal OFC coated with Matched Crystal Silver
• Jacket: Hulliflex Cobalt Blue
• Diameter: 5.8 mm

More Information

• MC Silver IT 65G Analogue Interconnect Cable, by Van Den Hul
