WiiM Bar Display-First Dolby Atmos Soundbar

WiiM Bar Display-First Dolby Atmos Soundbar, by WiiM home.

The new WiiM Bar brings cinematic sound, WiiM streaming, a 2.1-inch round touch display, and scalable home theatre expansion into one display-first smart soundbar. Start with immersive 3.0.2 Dolby Atmos® and DTS:X playback, then expand into a WiiM-powered 5.1.2 home cinema with compatible WiiM devices sold separately.

Elevate your living room with audiophile-grade 3.0.2 Dolby Atmos® and DTS:X spatial audio. Manage playback, adjust EQ, and view stunning album art directly from a vibrant 2.1” touchscreen. Ready for more? Wirelessly pair with compatible WiiM devices to seamlessly expand this perfect foundation into your ultimate 5.1.2 home theatre.

For Every Way You Listen

Start a movie through HDMI eARC and feel sound rise above the screen. Switch to music and see album art glow from the soundbar. Group with other WiiM devices for synchronized whole-home listening, or build out your living room with wireless surrounds and subwoofer support when you’re ready.

Control Without Friction

WiiM Bar gives you multiple ways to control your listening experience. Use the round touch display for quick playback, source selection, EQ, and Smart Presets. Open the WiiM Home App for streaming, grouping, routines, and deeper sound customization. Use Alexa, Google Assistant, or the included Voice Remote for easy everyday control.

Built For Cinema, Tuned For Music

Total freedom for your listening experience. Stream natively via Spotify and Tidal Connect, or dive into the WiiM Home App to personalize your sound, sync multi-room audio, and browse all your services in one elegant place.

An 8-driver acoustic system with 4 passive radiators, top-firing height channels, and 135W system power. Behind the sleek form is a serious acoustic system: three front mid-woofers, three front tweeters, two top full-range height drivers, and four passive radiators.

Together, they support a wide soundstage, clear vocals, height effects, and stronger bass performance from a single soundbar.

Features

• See the Sound - A glass-covered, vibrant 2.1-inch round touch display puts album art, track info, time, EQ, Smart Presets, Recently Played content, clock faces, dynamic wallpapers, and playback/source controls right on the soundbar.
• Immersive 3.0.2 Dolby Atmos® and DTS:X Playback - Top-firing height channels, HDMI eARC, and support for LPCM, Dolby Atmos/TrueHD/DD+, AC3, DTS, and DTS:X help deliver cinematic sound for movies, TV, and games.
• Expandable 5.1.2 WiiM Home Theater - Start with a 3.0.2 Dolby Atmos® soundbar and group with compatible WiiM devices to add wireless surrounds and subwoofer support, expanding into a 5.1.2 home theatre system.
• 8-Driver Acoustic System with 4 Passive Radiators - Three front mid-woofers, three front tweeters, two top full-range height drivers, and four passive radiators work together to support a wide soundstage, clear vocals, height effects, and bass performance from a single soundbar.
• RoomFit™ Auto-Correction - RoomFit™ helps tailor playback to your space, optimizing the listening experience for different room layouts and placements.
• Clear Voice, AI Dialogue Enhancement, and Night Mode - Dialogue-focused listening modes help improve vocal clarity, while Night Mode helps manage the dynamic range for lower-volume or late-night listening.
• Stream Your Way - Stream 20+ music services directly from the WiiM Home App, or connect through Google Cast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS, and Roon.
• Wi-Fi 6E and Bluetooth with LE Audio - Wi-Fi 6E, Ethernet, and Bluetooth with LE Audio provide flexible connectivity for streaming, control, and everyday listening.
• Scalable Whole-Home Audio - Seamlessly integrates with WiiM Amp, Ultra, Pro, Mini, and Edition speakers for synchronised multi-room music grouping.
• Control Your Way - Manage EQ, Smart Presets, and routines via the WiiM Home App, Alexa, Google Assistant, or the included Voice Remote 2 Lite.
• Future-Proof Performance - Regular firmware updates continuously unlock new features, services, and audio enhancements.

Specifications

• Audio System
• Acoustic system : 8-driver acoustic system with 4 passive radiators
• Front mid-woofers : 3 × 110 × 52 mm mid-woofers
• Front tweeters : 3 × 52 × 52 mm tweeters
• Top height drivers : 2 × 52 × 52 mm full-range drivers
• Passive radiators : 4 × 115 × 50 mm passive radiators, front × 2 and rear × 2
• Max system power : 135 W
• Native channel layout : 3.0.2
• Height effects : Top-firing height channels
• Audio Formats & Home Theater
• Supported audio formats : LPCM, Dolby Atmos/TrueHD/DD+, AC3, DTS, DTS:X
• Dolby Atmos support : Yes, via supported content and compatible input setup
• DTS:X support : Yes
• HDMI home theater connection : HDMI eARC
• Native configuration : 3.0.2 Dolby Atmos and DTS:X soundbar
• Expandable configuration : Up to 5.1.2 with compatible WiiM surround and subwoofer devices
• Surround expansion : Wireless surround support with compatible WiiM devices
• Subwoofer expansion : Wireless subwoofer support with compatible WiiM devices
• Smart Audio & EQ
• Room correction : RoomFit™ auto-correction
• Dialogue enhancement : Clear Voice and AI Dialog Enhancement
• Night listening : Night Mode
• Sound modes : Movie Mode, Music Mode, Voice Enhance Mode, Night Mode
• Preset EQ : 24 preset EQ settings
• Graphic EQ : 10-band Graphic EQ
• Parametric EQ : 10-band Parametric EQ, where supported in the WiiM Home App
• Per-source EQ : Supported via WiiM Home App, where available
• App customization : Sound modes, EQ, RoomFit™, input settings, grouping, and device preferences
• Display & On-Device Controls
• Display : Glass-covered 2.1-inch Hi-Res full-color round LCD touch screen
• Display type : Round touch display
• Display content : Album art, track information, time, EQ, Smart Presets, Recently Played, clock faces, dynamic wallpapers, and album art standby
• Playback controls : Play, pause, skip, and like
• Source controls : Source selection from the display
• EQ controls : Quick EQ access on the device; deeper EQ control in the WiiM Home App
• Smart Presets : One-tap access to favorite preset routines and content
• Recently Played : Access to recently played playlists, stations, and shows
• Personalization : Multiple clock faces, dynamic wallpapers, and album art standby
• Proximity-lit capacitive buttons : Volume +, Volume –, Play/Pause, Source Switch
• Status LED : RGB+W status LED
• App, Voice & Remote Control
• App control : WiiM Home App
• Voice control : Alexa and Google Assistant
• Remote : WiiM Bar Remote
• Remote controls : Playback, volume, source switching, sound modes, mute/unmute, standby, and voice control where available
• On-device control : 2.1-inch round touch display and proximity-lit capacitive buttons
• Setup control : WiiM Home App via WiFi or Ethernet
• Ecosystem control : Manage streaming, grouping, EQ, presets, and compatible WiiM devices from the WiiM Home App
• Inputs, Outputs & Connectivity
• HDMI : HDMI eARC
• Optical : Optical In
• Analog input : Line In
• Ethernet : 10/100 Mbps Ethernet
• USB : USB Host for storage
• USB Audio Input or Output
• WiFi : WiFi 6E
• WiFi bands : 2.4 GHz, 5 GHz, and 6 GHz
• WiFi standard : 802.11 b/g/n/ax
• Bluetooth : Bluetooth 5.4
• Bluetooth profiles : BLE, A2DP Rx/Tx, AVRCP, HID
• LE Audio : Supported via software update
• Bluetooth input : Stream from compatible phones, tablets, TVs, and laptops
• Bluetooth output : Output to compatible Bluetooth speakers, headphones, or earphones, where supported
• Wired network behavior : Ethernet available for a stable wired network connection
• Streaming & Protocols
• Streaming app : WiiM Home App
• In-app streaming : Stream 20+ music services through the WiiM Home App
• Casting and streaming protocols : Google Cast Audio / Chromecast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS, Roon
• Example music services : Spotify, Amazon Music, YouTube Music, TIDAL, Qobuz, Deezer, TuneIn, SoundCloud, Pandora, iHeartRadio, vTuner, Napster, SoundMachine, KKBOX, Soundtrack Your Brand
• AirPlay 2 : Not supported
• Network playback : WiFi, Ethernet, DLNA/UPnP, and WiiM Home App
• Direct app control : Supported with compatible services such as Spotify Connect, TIDAL Connect, Qobuz Connect, and Google Cast Audio
• Multi-Room & WiiM Ecosystem
• WiiM multi-room audio : Group WiiM Bar with compatible WiiM devices for synchronized multi-room listening
• Compatible WiiM ecosystem : Designed to integrate with WiiM Amp, WiiM Ultra, WiiM Pro, WiiM Mini, and WiiM Edition speakers for multi-room music grouping
• Home theater expansion : Expand from 3.0.2 to up to 5.1.2 with compatible WiiM surround and subwoofer devices
• Surround setup : Use compatible WiiM devices as wireless surround channels
• Subwoofer setup : Add compatible WiiM subwoofer support for deeper bass
• Other multi-room options : Alexa multi-room and Google Cast multi-room, where supported
• Physical input multi-room : For Line In, Optical In, HDMI eARC, or Bluetooth as multi-room sources, use a WiiM-device group
• USB Media Library
• USB function : USB Host for storage
• Media library : Access a personal media library from connected USB storage
• Media server : Can act as a media server for other WiiM and DLNA devices on the same network
• Supported storage examples : USB drive or compatible external storage
• Supported file systems : FAT32, NTFS, EXT4, where supported
• Playback control : Browse and control USB media through the WiiM Home App
• Physical
• Dimensions : 1060 × 105 × 74 mm
• Height without foot : 70 mm
• Weight : 5 kg / 11.02 lb
• Placement : TV console or wall mount
• Wall mounting : Wall brackets included
• Display location : Front-facing 2.1-inch round touch display
• On-device controls : Top-panel capacitive controls and front touch display
• Status light : RGB+W LED status indicator
• Power
• Power input : 100–240V AC
• Frequency : 50/60 Hz
• Max system power : 135 W
• Power cable : Included

Included

• WiiM Bar
• WiiM Bar Remote
• User Guide
• Power Cable
• HDMI Cable
• Optical Cable
• Wall brackets × 2 with screws
